商品の詳細:
|
| 製品名: | アラミドハニカムコア | サイズ: | キュートミー化 |
|---|---|---|---|
| 密度: | 48, 96, 128kg/m3 | 厚さ: | 1520mm または コスチューム |
| セルサイズ: | 4.89.6mm または コスチューム | 利点: | 高強度抗疲労剤 |
| 材料: | アラミド繊維紙 | 色: | 茶色 |
| パッケージ: | 合板ケース | アプリケーション: | 柵の運輸、スポーツ プロダクトまたは他 |
| ハイライト: | 1220x2440mm aramid honeycomb core,lightweight aramid paper honeycomb,marine manufacturing honeycomb core |
||
| Product Code | Cell Size (mm/inch) | Density (kg/m³) | Compression Strength (MPa) | L-Shear Strength (MPa) | W-Shear Strength (MPa) |
|---|---|---|---|---|---|
| Commercial Grade Aramid Honeycomb Core | |||||
| BHC1313-3.2-48 | 3.2 (1/8") | 48 | 1.9 | 1.16 | 0.62 |
| BHC1313-3.2-64 | 3.2 (1/8") | 64 | 3.1 | 1.48 | 0.82 |
| BHC1313-3.2-80 | 3.2 (1/8") | 80 | 4.7 | 1.95 | 1.05 |
| BHC1313-3.2-96 | 3.2 (1/8") | 96 | 6.6 | 2.45 | 1.42 |
| BHC1313-4.8-32 | 4.8 (3/16") | 32 | 0.9 | 0.58 | 0.36 |
| BHC1313-4.8-48 | 4.8 (3/16") | 48 | 2.6 | 0.98 | 0.56 |
| BHC1313-4.8-64 | 4.8 (3/16") | 64 | 3.4 | 1.7 | 0.92 |
| BHC1313-4.8-80 | 4.8 (3/16") | 80 | 6 | 1.95 | 1.1 |
| BHC1313-4.8-96 | 4.8 (3/16") | 96 | 7.3 | 2.26 | 1.32 |
| BHC1313-6.4-24 | 6.4 (1/4") | 24 | 0.54 | 0.34 | 0.18 |
| BHC1313-6.4-32 | 6.4 (1/4") | 32 | 0.8 | 0.54 | 0.3 |
| BHC1313-6.4-48 | 6.4 (1/4") | 48 | 2.05 | 1 | 0.56 |
| BHC1313-6.4-64 | 6.4 (1/4") | 64 | 3.4 | 1.54 | 0.79 |
| BHC1313-9.5-24 | 9.5 (3/8") | 24 | 0.52 | 0.32 | 0.16 |
| BHC1313-9.5-32 | 9.5 (3/8") | 32 | 0.68 | 0.56 | 0.29 |
| BHC1313-9.5-48 | 9.5 (3/8") | 48 | 9.6 | 1.15 | 0.66 |
| Aerospace Grade Aramid Honeycomb Core | |||||
| BHC1313A-3.2-48 | 3.2 (1/8") | 48 | 2 | 1.26 | 0.72 |
| BHC1313A-3.2-64 | 3.2 (1/8") | 64 | 3.2 | 1.58 | 0.92 |
| BHC1313A-3.2-80 | 3.2 (1/8") | 80 | 4.8 | 2.05 | 1.15 |
| BHC1313A-3.2-96 | 3.2 (1/8") | 96 | 6.7 | 2.55 | 1.52 |
| BHC1313A-3.2-128 | 3.2 (1/8") | 128 | 11.4 | 3.05 | 1.88 |
| BHC1313A-3.2-144 | 3.2 (1/8") | 144 | 13.3 | 3.15 | 2 |
| BHC1313A-4.8-32 | 4.8 (3/16") | 32 | 1 | 0.68 | 0.46 |
| BHC1313A-4.8-48 | 4.8 (3/16") | 48 | 2.7 | 1.08 | 0.66 |
| BHC1313A-6.4-48 | 6.4 (1/4") | 48 | 2.15 | 1.1 | 0.66 |
| BHC1313A-9.5-48 | 9.5 (3/8") | 48 | 9.7 | 1.25 | 0.76 |
